| 供電電源 | 10~30V DC | |
| 平均(jun)功耗 |
485型：0.35W 模擬量型：1.0W |
|
| 輸出信號 | 485輸(shu)出（標準ModBus協議）、4~20mA、0~5V、0~10V | |
| 重復性(xing) |
NH3/H2/CO(1000ppm)/H2S/CH4/NO2/SO2/O3/PH3/CH2O/CL2:≤2% CO(2000ppm) :≤3% O2/N2:≤1% |
|
| 穩定性 | CO(1000ppm)/H2S/H2/NO2/SO2/NH3/PH3/CL2 | ≤2%信號值/月 |
| CH4/O3/CH2O | ≤7%信號值/年 | |
| CO(2000ppm)/O2/N2 | ≤5%信號(hao)值/年(nian) | |
| 工作溫度 | H2/CO/H2S/CH4/NO2/SO2/O2/NH3/PH3/O3/CH2O/CL2/N2：-20~50℃ | |
| 工作濕度 |
NH3/H2/CO/H2S/NO2/SO2/O3/PH3/CH2O/CL2：15~90%RH 無冷凝 O2/N2：5~95%RH 無冷凝 ; CH4：0~95%RH 無冷凝 |
|
| 工(gong)作壓力 | NH3/H2/CO(1000ppm)/H2S/SO2/O2/O3/PH3/CH2O/N2/CL2 | 90~110kPa |
| NO2 | 91~111kPa | |
| CH4 | 80~116kPa | |
| CO(2000ppm) | 80~120kPa | |
| 預熱(re)時間(jian) |
NH3/H2/CO/H2S/CH4/NO2/SO2/O3/O2/PH3/CH2O/CL2: ≥5min N2:≥15min |
|
| 防爆標志(zhi) | Ex db IIC T6 Gb；Ex tb IIIC T80℃ Db | |
| 繼電器帶負載(zai)能力(li) | 250VAC 1A/30VDC 1A | |
| RS- | 公司代號 | |||||
| FPC- | 帶(dai)顯示防爆殼體 | |||||
| FPC-N | 不帶顯示(shi)防爆殼體 | |||||
| O2- | 30VOL- | O2變送器30VOL量程 | ||||
| H2S- | 100P- | H2S變送器100 ppm量程 | ||||
| CH4- | 100LEL- | CH4變送器100 LEL量程 | ||||
| CO- | 1000P- | CO變送(song)器(qi)1000 ppm量程(cheng) | ||||
| 2000P- | CO變送器2000ppm量程 | |||||
| NO2- | 20P- | NO2變送(song)器20ppm量程 | ||||
| 2000P- | NO2變(bian)送器2000ppm量程(cheng) | |||||
| SO2- | 20P- | SO2變送(song)器(qi)20ppm量程 | ||||
| 2000P- | SO2變送器2000ppm量(liang)程(cheng) | |||||
| H2- | 1000P- | H2變送器1000ppm量程 | ||||
| 40000P- | H2變(bian)送器40000ppm量程 | |||||
| NH3- | 50P- | NH3變送器50ppm量程 | ||||
| 100P- | NH3變送器100ppm量程 | |||||
| PH3- | 20P- | PH3變送(song)器(qi)20ppm量程 | ||||
| O3- | 100P- | O3變送(song)器100ppm量(liang)程 | ||||
| CH2O- | 5P- | CH2O變(bian)送器5ppm量程 | ||||
| CL2- | 20P- | CL2變(bian)送器20ppm量程(cheng) | ||||
| 50P- | CL2變送器50ppm量程 | |||||
| 100P- | CL2變送(song)器(qi)100ppm量程 | |||||
| N2- | 99VOL- | N2變送器70~99.9%VOL量程 | ||||
| N01- | RS485（ModBus協議） | |||||
| I20- | 4~20mA電流輸(shu)出 | |||||
| V05- | 0~5V電壓輸出(chu) | |||||
| V10- | 0~10V電(dian)壓輸出 | |||||
| 空 | 無聲光報警器 | |||||
| A | 加聲光報警器 | |||||
| R01 | 無源繼電器輸出(chu) | |||||
